DPHD-80411-810
Trang chủ » Tât cả sản phẩm » Phụ tùng máy cám viên BUHLER » DPHD-80411-810
Mô tả sản phẩm
| Item |
Part. No. |
C |
Designation |
Number |
| 001 |
DPHD-80341-810 |
|
Roll holder module |
1 |
| 002 |
DPHD-80344-810 |
|
Roll adjustment gearing |
1 |
| 005 |
DPHD-80040-810 |
|
Grease distributor |
1 |
| 010 |
DPHD-10321-010 |
E3 |
Eccentric bushing |
1 |
| 012 |
UXN -10066-063 |
E3 |
Screw bolt M20x130 |
3 |
| 013 |
UXN -56001-024 |
E2 |
Deep groove ball bearing D 17/35×10 |
1 |
| 014 |
UNN -14023-028 |
E3 |
Tab washer D 150/205 |
1 |
| 015 |
UNN -12026-028 |
E3 |
Shaft nut M150x2.0 |
1 |
| 019 |
UNN -14002-005 |
E3 |
Washer D 13/37×3 |
1 |
| 020 |
UNN -10008-334 |
E3 |
Hexagon head bolt M12x20 |
1 |
| 022 |
UXN -14002-006 |
E3 |
Washer D 40/20.5×8 |
15 |
| 023 |
UNE -26311-014 |
E3 |
Proximity switch, inductive |
1 |
| 024 |
UNN -12001-164 |
E3 |
Hex nut 0.8d M20 |
3 |
| 025 |
UNN -28001-418 |
E3 |
Parallel key 36/20×100 |
1 |
| 026 |
UNN -44021-269 |
E2 |
O-ring D 3.53×66.27 |
3 |
| 040 |
UNN -24037-026 |
E2 |
Angle swivel union |
4 |
| 042 |
UNN -24047-102 |
E2 |
Cross manifold block |
1 |
| 045 |
DPHD-80348-450 |
E2 |
Pneumatic hose |
1 |
| 048 |
UXN -24024-003 |
E2 |
Reducing union D 8/6 |
4 |
