DPHD-95221-810
Mô tả sản phẩm
Manual press unit, fastened, lubricated centrally (Part 2)
| Item | Part. No. | C | Designation | Number | |
| 001 | DPHD-80352-810 | Roll holder module, standard | 1 | ||
| 002 | DPHD-80412-810 | Manual roll adjustment | 1 | ||
| 005 | DPHD-80040-810 | Grease distributor | 1 | ||
| 010 | DPHD-10321-010 | E3 | Eccentric bushing | 1 | |
| 021 | UNN -10008-334 | E3 | Hexagon head bolt M12x20 | 1 | |
| 022 | UNN -14002-005 | E3 | Washer D 13/37×3 | 1 | |
| 024 | UNN -44021-269 | E2 | O-ring D 3.53×66.27 | 3 | |
| 025 | UNN -12026-028 | E3 | Shaft nut M150x2.0 | 1 | |
| 026 | UNN -14023-028 | E3 | Tab washer D 150/205 | 1 | |
| 028 | UNN -28001-418 | E3 | Parallel key 36/20×100 | 1 | |
