DPHE-80197-810
Mô tả sản phẩm
03 DPHE-80217-810 Complete central lubrication system 1 PC
04 DPHE-80089-810 Roll adjusting drive 1 PC
06 DPHD-80246-810 Pressure reinforcement module 1 PC
15 UNN -12026-031 E3 Shaft nut KM-36, M180x3.0 1 PC
22 MDDM-40090-010 E3 Pneumatic valve plate 1 PC
23 UNN -24037-008 E2 Screw-in connector D 8 G1/4″ 2 PC
24 UNS -16125-002 E2 Manual slide valve G1/4″ 1 PC
29 UNN -24049-652 E2 Coupling nipple D 7.6 1 PC
36 UNN -10011-254 E3 Hexagon bolt M20x70 stainless 4 PC
37 UXN -14002-006 E3 Washer 40/20.5×8 4 PC
39 UXN -14002-013 E3 Washer 50/24.5×8 17 PC
40 UNN -24049-650 E2 Coupling sleeve open G1/4″ 1 PC
41 DPHE-80197-410 E2 Coupling hose 1 PC
43 UNN -10008-533 E3 Hexagon bolt M24x140, galvanised 12 PC
44 UXE -26310-151 E2 Proximity switch, inductive 1 PC
46 UNN -22006-005 E3 Hose clamp OETIKER D 11-13 2 PC
49 UXE -24002-111 E3 Cable box M12x1 with cable 10 m 1 PC
50 UXE -24002-150 E3 Locking protection for M12 1 PC
52 DPHD-80381-810 E3 Strain relief bracket, bottom 1 PC
53 DPHD-80380-810 E3 Strain relief bracket, top 1 PC
54 UNN -14000-005 E3 Washer D 8.4/16×1.6 1 PC
55 UNN -10008-212 E3 Hexagon bolt M8x16, galvanised 1 PC
56 UNN -14002-001 E3 Washer D 6.4/18×1.6 4 PC
57 UNN -10008-150 E3 Hexagon bolt M6x10, galvanised 4 PC
58 UNN -22008-201 E3 Cable pressing sleeve 6/4×6 4 PC
59 DPHE-80197-590 E3 Wire rope 2 PC
