PM 717
Mô tả sản phẩm
| 1 | 131257209 | Base frame |
| 2 | 100003525 | Hex. Screw M20 x 60 DIN 931 |
| 3 | 131124970 | Spring washer ø20 DIN 127B |
| Coupling Winflex T2 ø90/ø65 incl. | ||
| 10 | 131444114 | 131165086coupling hub winflex T2 Ø090 H7 131271701 coupling hub winflex T2 Ø065 H7 |
| 131147394 coupling housing T2 Incl springs | ||
| – and other type of Coupling | ||
| 11 | 131195514 | Coupling element Winflex T2 |
| 12 | 131267643 | Guard for coupling |
| 13 | 131131602 | Hex. Screw M6 x 20 D933 |
| 20 | Motor 250kW, 1450 o/min. | |
| Motor 355kW, 1450 o/min. | ||
| – and others | ||
| 21 | 131089518 | Hex. Screw M24 x 80 DIN 931 |
| 100002512 | Hex. Screw M30 x 100 DIN 931 | |
| 22 | 131126459 | Facetskive Ø24 DIN 125 B |
| 131126452 | Facetskive Ø30 DIN 125 B | |
| 23 | 131238436 | Shim 0,5 |
| 131238434 | Shim 0,7 | |
| 131238502 | Shim 1,0 | |
| 131238432 | Shim 2,0 | |
| 25 | 131259559 | Motor console |
