PM 919
Mô tả sản phẩm
| Pos. | S-M DK No. |
S-M USA No. |
Description | No. off |
| 1 | 061924 | Feed cylinder | 1 | |
| 2 | 062085 | Deflector | 1 | |
| 3 | 005469 | Hex. Screw M20 x 60 FZB DIN 933 | 2 | |
| 5 | 569303 | Facet disc ø20 DIN 125 A | 2 | |
| 6 | 061922 | Front plate (PM 919XW) | 1 | |
| 062128 | Front plate (PM 919TW) | Alt. | ||
| 7 | 008820 | Hex. Screw M20 x 100 FZB DIN 933 | 4 | |
| 8 | 005171 | Spring washer Ø20 FZM DIN 127 B | 4 | |
| 10 | 060030 | Bridge | 2 | |
| 11 | 060037 | Slide bearing PAP 2010 | 2 | |
| 12 | 059975 | Pin | 2 | |
| 14 | 059976 | Eye bolt | 2 | |
| 15 | 000670 | Nut M20 DIN 934 | 2 | |
| 16 | 059968 | Roller adjustment arm | 2 | |
| 17 | 060039 | Slide bearing PAP 2030 | 2 | |
| 18 | 005469 | Hex. Screw M20 x 60 FZB DIN 933 | 2 | |
| 19 | 569303 | Facet disc ø20 FZB DIN 125 B | 2 | |
| 20 | 005709 | Hex. Screw M16 x 140 FZB DIN 933 | 2 | |
| 21 | 002593 | Facet disc ø16 DIN 125 A | 2 | |
| 23 | 061649 | Drilling bushing A31 X56 DIN179 | 2 | |
| 24 | 032018 | Scraper knife | 2 | |
| 25 | 062082 | Roller main shaft | 1 | |
| 26 | 004534 | Pointed screw M10 x 16 DIN 912 | 2 | |
| 30 | 025922 | Hex. Screw M30 x 100 DIN931 (PM 919XW) | 2 | |
| 059551 | Hex. Screw M30 x 160 DIN931 (PM 919TW) | Alt. | ||
| 31 | 028946 | Facet disc Ø30 DIN125B | 2 | |
| 33 | 031637 | Hex. Screw M24 x 60 FZB DIN 931 | 8 | |
| 34 | 033850 | Tension disc Ø24 A2 HB200 | 8 |
