PM 919
Mô tả sản phẩm
ROLLER, 3 ROLLER SYSTEM
| Pos. | S-M DK No. |
S-M USA Nr. |
Description | No. off |
| 1 | 032546 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919XW) | ||||
| 1 | 032022 | Roller, complete, grooved, closed end, incl. | Alt. | |
| pos. 2-13, (PM 919XW) | ||||
| 1 | 032268 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919TW) | ||||
| 1 | 034989 | Roller, complete, grooved, closed end, incl. | Alt. | |
| pos. 2-13, (PM 919TW) | ||||
| 2 | 032060 | MB032060/01 | Distance ring, (PM 919XW) | 1 |
| 2 | 032267 | MB032267/01 | Distance ring, (PM 919TW) | Alt. |
| 3 | 032510 | WA44326 | Conical roller bearing HH 224346/HH 224310 | 2 |
| 5 | 032508 | B1728-320/01 | Labyrinth sealing – inner | 2 |
| 6 | 036393 | Rollershell perforated, Ø8,0, (PM 919XW) | ||
| 6 | 029839 | Rollershell grooved, closed end, (PM 919XW) | Alt. | |
| 6 | 036600 | Rollershell perforated, Ø8,0, (PM 919TW) | ||
| 6 | 036601 | Rollershell grooved, closed end, (PM 919TW) | Alt. | |
| 7 | 031557 | WA16669 | Lock ring I 210 x 4,75 | 2 |
| 8 | 032507 | B1728-321/01 | Labyrinth sealing – outer | 2 |
| 9 | 031558 | WA25870 | Lock ring U 114 x 2,77 | 1 |
| 10 | 032509 | C3867-323-00 | Roller shaft, (PM 919XW) | 1 |
| 10 | 035411 | C3867-375-01 | Roller shaft, (PM 919TW) | Alt. |
| 11 | 031520 | WA26576 | O-ring Ø75,8 x 3,53 NBR | 2 |
| 12 | 032512 | WA13295 | Shaft nut AN-22 | 1 |
| 13 | 032513 | WA43774 | Lock plate TW 122 | 1 |
ROLLER, 2 ROLLER SYSTEM, AUTOMATIC ROLLER ADJUSTMENT
| Pos. | S-M DK No. |
S-M USA Nr. |
Description | No. off |
| 1 | 069666 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919W) | ||||
| 1 | 063105 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919XW) | ||||
| 1 | 063219 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919TW) | ||||
| 1 | 063653 | Roller, complete, grooved, closed end, (CEC) incl. pos. 2-13, (PM 919TW) |
||
| 2 | 060230 | Distance ring, (PM 919W and PM 919XW) | 1 | |
| 2 | 062130 | Distance ring, (PM 919TW) | Alt. | |
| 3 | 051610 | WA88779 | Conical roller bearing HH 228310/HH 228349 | 2 |
| 5 | 051608 | B1728-324/01 | Labyrinth sealing – inner | 2 |
| 6 | 069664 | Rollershell perforated, Ø8,0, (PM 919W) | ||
| 6 | 063052 | Rollershell perforated, Ø8,0, (PM 919XW) | ||
| 6 | 063645 | Rollershell perforated, Ø8,0, (PM 919TW) | ||
| 6 | 063647 | Rollershell grooved, closed end, (CEC), | ||
| (PM 919TW) | ||||
| 7 | 051614 | WA88780 | Lock ring I 254 x 4,80 | 2 |
| 8 | 051607 | B1728-325/01 | Labyrinth sealing – outer | 2 |
| 9 | 051615 | WA25872 | Lock ring U 127 | 1 |
| 10 | 063104 | Roller shaft, (PM 919W and PM 919XW) | 1 | |
| 10 | 063220 | Roller shaft, (PM 919TW) | Alt. | |
| 11 | 031520 | WA26576 | O-ring Ø75,8 x 3,53 NBR | 2 |
| 12 | 575599 | WA104811 | Shaft nut KM25 | 1 |
| 13 | 575600 | WA104840 | Lock plate MB25 | 1 |
ROLLER, 2 ROLLER SYSTEM, MANUAL ROLLER ADJUSTMENT
| Pos. | S-M DK No. |
S-M USA Nr. |
Description | No. off |
| 1 | 064961 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919W) | ||||
| 1 | 060235 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919XW) | ||||
| 1 | 068845 | Roller, complete, grooved, closed end, (CEC) | ||
| incl. pos. 2-13, (PM 919XW) | ||||
| 1 | 062487 | Roller, complete, perforated Ø8,0, incl. pos. 2- | ||
| 13, (PM 919TW) | ||||
| 1 | 082179 | Roller, complete, grooved, incl. pos. 2-13, (PM | ||
| 919TW) | ||||
| 1 | 080468 | Roller, complete, grooved, closed end, (CEC) incl. pos. 2-13, (PM 919TW) |
||
| 2 | 060230 | Distance ring, (PM 919W and PM 919XW) | 1 | |
| 2 | 062130 | Distance ring, (PM 919TW) | Alt. | |
| 3 | 051610 | WA88779 | Conical roller bearing HH 228310/HH 228349 | 2 |
| 5 | 051608 | B1728-324/01 | Labyrinth sealing – inner | 2 |
| 6 | 064910 | Rollershell perforated, Ø8,0, (PM 919W) | ||
| 6 | 064962 | Rollershell perforated, Ø8,0, (PM 919XW) | ||
| 6 | 068899 | Rollershell grooved, closed end, (CEC), | ||
| (PM 919XW) | ||||
| 6 | 063057 | Rollershell perforated, Ø8,0, (PM 919TW) | ||
| 6 | 082180 | Rollershell grooved, (PM 919TW) | ||
| 6 | 080467 | Rollershell grooved, closed end, (CEC), (PM | ||
| 919TW) | ||||
| 7 | 051614 | WA88780 | Lock ring I 254 x 4,80 | 2 |
| 8 | 051607 | B1728-325/01 | Labyrinth sealing – outer | 2 |
| 9 | 051615 | WA25872 | Lock ring U 127 | 1 |
| 10 | 060228 | Roller shaft, (PM 919W and PM 919XW) | 1 | |
| 10 | 062129 | Roller shaft, (PM 919TW) | Alt. | |
| 11 | 031520 | WA26576 | O-ring Ø75,8 x 3,53 NBR | 2 |
| 12 | 051612 | WA13295 | Shaft nut TAN-24 | 1 |
| 13 | 051613 | WA43774 | Lock plate TW 124 | 1 |
