PM 919
Mô tả sản phẩm
| Pos. | S-M DK No. |
Description | No. off | ||||
| 1 | 067440 | Lubrication automat w/counter for 1 press, complete Incl.pos. 2-30 – 230V | 1 | ||||
| 067441 | Lubrication automat w/counter for 1 press, complete Incl.pos. 2-30 – 115V | alt. | |||||
| 025537 | Lubrication automat w/counter for 2 presses, complete incl. Pos. 2-30 – 230v | alt. | |||||
| 039424 | Lubrication automat w/counter for 2 presses, complete incl. Pos. 2-30 – 115v | alt. | |||||
| 030489 | Lubrication automat w/counter for 3 presses, complete incl. Pos. 2-30 – 230v | alt. | |||||
| 035843 | Lubrication automat w/counter for 3 presses, complete incl. Pos. 2-30 – 115v | alt. | |||||
| 2 | 068001 | Lubrication control for 1 press, 230V | 1 | ||||
| 061437 | Lubrication control for 1 press, 115V | Alt | |||||
| 011982 | Lubrication control for 2 and 3 presses, 230V | alt | |||||
| 011681 | Lubrication control for 2 and 3 presses, 115V | alt. | |||||
| 3 | 087565 | Inductive sensor for control for 1 press | alt. | ||||
| 091490 | Inductive sensor for control for 2 and 3 presses | ||||||
| 4 | Manometer 0-10 bar, 8-8439 | 1 | |||||
| 5 | 033050 | Air regulator 8-8456 | 1 | ||||
| 6 | Hinging for air regulator 8-8440 | 1 | |||||
| 7 | Straight union joint L 1/4 – 6 mm | 1 | |||||
| 8 | Air hose 6 x 4 blue 8-8757 | 1 | |||||
| 9 | 033052 | Solenoid valve 1/4″ 8-8788 | 1 | ||||
| 10 | Angle 1/4″ 6 mm 8-8725 | 1 | |||||
| 11 | 025550 | Plug M10 x 1 | 4 | ||||
| 12 | 025551 | Cobber packing 10 mm | 4 | ||||
| 13 | 030001 | Angle union joint 1/8 NPV inner/1/8 NPT outer 67368 DK | 1 | ||||
| 14 | Hex. nipple 1/4 x 1/8 10772 | 1 | |||||
| 15 | 081941 | Union joint with stop 519-30911-1 | 1 | ||||
| 081942 | Packing for union joint | 1 | |||||
| 16 | 006089 | Non-retur valve 6 mm | 2 | ||||
| 17 | 005744 | By-pass 6 mm | 2 | ||||
| 18 | 005997 | Cut ring steel 6 mm | 2 | ||||
| 19 | 005761 | Cut ring brass 6 mm | 2 | ||||
| 20 | 006085 | Copper pipe 6 mm | 3 | ||||
| 22 | 027347 | Grease distributor block SSV-6K | 1 | ||||
| 25 | 081165 | Te-piece 6 mm x 1/4 NPT 69089 DK | 2 | ||||
| 26 | 033053 | Solenoid valve high pressure, 220 V, 8-8057, 2 or 3 pcs. | |||||
| 27 | Hex. nipple 1/4 x 1/4 MS | 2 | |||||
| 29 | Coupling 1/4 8-8136 | 4 | |||||
| 30 | 063568 | Hose 1/4 8-8135 | 2 | ||||
| 34 | 025510 | Pump central, complete incl. pos. 35-48 | 1 | ||||
| 35 | Air hose blue 6 x 4 8-8757 | 1 | |||||
| 36 | High pressure hose 1/4 8-8135 | 1 | |||||
| 37 | Clamp fitting L 1/4 6 mm 8-8721 | 1 | |||||
| 38 | Snap coupling 815 | 1 | |||||
| 39 | Coupling nipple 11659 | 1 | |||||
| 40 | Coupling 1/4 8-8136 | 1 | |||||
| 41 | 066621 | Hex. nipple 1/4 x 1/4 MS 10462 DK | 1 | ||||
| 45 | 033054 | Pump 2½” air driven 82054 | 1 | ||||
| 46 | 033055 | Repair set for pump 83054 | 1 | ||||
| 47 | 033056 | Repair set for pump pipe 83001 | 1 | ||||
| 50 | Cover for drum 81523-E200 | 1 | |||||
| 51 | Follow plate for drum 83366 | 1 | |||||
| 52 | 028474 | Grease sensor, complete (please also see page 5.153) | 1 | ||||
